L Band Cavity Bandpass Filter With Passband From 1345MHz-1405MHz

CBF01345M01405Q06A is a L Band coaxial bandpass filter with a passband frequency of 1345MHz-1405MHz. The typical insertion loss of the bandpass filter is 0.4dB . The rejection frequencies are DC-1245MHz and 1505-3000MHz with typical rejection is 60dB. The typical passband R.L of the filter is better than 23dB. This RF cavity band pass filter design is built with SMA connectors that are female gender

Whatsapp Download as PDF

Product Detail

Product Tags

Description

This L Band cavity bandpass filter offers excellent 57dB out-of-band rejection and is designed to be installed in-line between the radio and antenna, or integrated within other communication equipment when additional RF filtering is required to improve network performance. This bandpass filter is ideal for tactical radio systems, fixed site infrastructure, base station systems, network nodes, or other communication network infrastructure that operates in congested, high-interference RF environments.

Fetures

• Small size and excellent performances

• Low passband insertion loss and high rejection

• Broad, high frequency pass and stopbands

• Lumped-element, microstrip, cavity , LC structures are avaliable according to different applications

Availability: NO MOQ , NO NRE and free for testing

Pass Band	1345MHz-1405MHz
Rejection	≥57dB@DC-1245MHz ≥57dB@1505-3000MHz
Insertion loss	≤1.0dB
Ripple	≤0.5dB
Return Loss	≥23dB
Average Power	200W

OEM and ODM servies are welcomed . Lumped-element, microstrip, cavity , LC structures custom filters are avaliable according to different applications . SMA, N-Type, F-Type, BNC, ,TNC , 2.4mm and 2.92mm connectors are avaliable for option

Please feel freely to contact with us if you need any different requirements or a customized bandpass filter : sales@concept-mw.com .
